No.

Project

Specification

1

Battery Configuration

1P16S

2

Nominal Voltage

51.2V

3

Working Voltage Range

42V~58.4V

4

Nominal Capacity

100Ah

5

Nominal Power

5.12KWh  ( 95%DOD)

6

Standard Charging/ Discharging Current

50A @25±2C

7

Maximum Charging Current

100A@25± 2C

8

Maximum Discharging Current

100A @25± 2C

9

Working Ambient Temperature

0 ~ 40C(Charge)

-10 ~ 40C(Discharge)

10

Storage Temperature & Humidity

- 10C~35C (within 1 month storage) 25±2C (within 3 months storage)

65%±20%RH

11

Size (L x W x H)

(563) × (399)× (162)mm

12

Weight

48Kg± 3kg

13

Cycling Lifespan

6000 cycles @25C

50A Charging/discharging current 80%

DOD

18

IP Rate

IP 2X

19

Communication

CAN or RS485

20

Altitude

0-3000m

21

Humidity Range

5~80%
